1.55MP Global Shutter Machine Vision MIPI CSI-2 Camera, MV-XAVIER-ORIN-1CAM-IMX296M for Jetson AGX-Xavier,Orin and TX2 Devkit

Description

• 1.55M Pixel IMX296LLR-C Pregius Global Shutter
• Has a small size and rich functions
• Open source driver and demo.Support Jetson AGX XAVIER,AGX ORIN,TX2
• Hardware and Software trigger source
• Suitable for machine vision,Pls refer to veye.cc for more info

Package List n*MV-MIPI-IMX296M 1*ADP-N4 Screws and Cables
Product introduction
MV-MIPI-IMX296M is a 1.55M MONO industrial camera with MIPI interface.
This camera has a small size (29*29mm) and rich functions, so it is suitable for integration as an image acquisition component. 1.55M Pixel IMX296LLR-C MIPI CSI-2 Interface Mono-8,Mono-10 Data Format Video streaming mode,Trigger mode Hardware and Software trigger source Support trigger frame number, interval, delay, trigger filter function Strobe synchronization ROI Flexible frame rate settings

Technical Details
Shutter Mode: Global Shutter
Sensor: IMX296LLR-C Pregius
Color: MONO
Image Size: 1/2.9''
Unit Cell Size: 3.45m *3.45m
Resolution: 1456*1088
Max Frame Rate: 1456*1088 @ 60.3fps
Gain: 0 dB to 24 dB: Analog Gain (0.1 dB step)
24.1 dB to 48 dB: Analog Gain: 24 dB + Digital Gain: 0.1 dB to 24 dB (0.1 dB step)
Exposure Time: <= 1/max frame rate
Shutter Mode: AE,ME,AE Once
ISP: Bad Pixel Correction,8bit GAMMA,User Lookup Table
ADC: 10 bit
Pixel Format: Mono8,Mono10,UYVY 8bit
Working Mode: Hardware Trigger,Software Trigger,Video streaming mode
Trigger Mode: Trigger Filtering,Trigger Delay,Trigger Polarity Control
Strobe Mode: Strobe Output Control,Strobe Delay,Strobe Polarity Control
