AudioControl LC8i 8-Channel Active Line Output Converter with Auxiliary Input for Adding Subwoofers, Amplifiers to Factory Car Audio Receiver or Head Unit, Includes ACR-1 Dash Remote Bass Knob

Description

• : Convert speaker-level signals up to 400W (40V) per channel from your factory stereo or amplifier to high quality pre-amp output signals directed to aftermarket subwoofers, amplifiers, and processors.
• : Including the use of factory volume and steering wheel controls.
• : Play audio from your smartphone, satellite radio, or other devices.
• ' : Use the ACR-3 multi-functional dash knob remote to choose between input sources and adjust subwoofer output level or aux volume.
• - : The Signal Bus switch allows you to combine multiple input signals to a single channel output when connecting to factory systems with dedicated outputs for highs, mids, and lows.
• : The optional AutoMode feature automatically creates a dedicated subwoofer output from factory front/rear audio systems in order to drive a subwoofer amp and crossover.
• : Selectable ground isolation switch allows you to remove ground buzz or alternator whine.
• - : Features selectable Great Turn On (GTO) signal sense and audio sense to automatically power the LOC or remote 12V input for manual control.cks
• : By using the Remote Out, this line out converter can trigger up to 2 devices down the signal chain including amplifiers, line drivers, crossovers, or any other device with a Remote In.
• : Designed with a compact slim chassis to fit discreetly in your car without taking up extra room. Dimensions: 4.75L x 8.6D x 1.2H.

Add amps to your factory system and play music from your phone AudioControl's LC8i 8-channel line output converter (LOC) allows you to add aftermarket amps, speakers, and subs to your car's factory radio, so you can enjoy better and more powerful sound without losing climate controls, voice-activated functions, or other built-in factory features. The LC8i accepts speaker-level signals, so you can use it with just about any setup, even high-powered amplified systems. Now you can plug your music into the system The LC8i features RCA auxiliary inputs, with an independent volume control, so you can play music through the system from whatever portable source you own via its headphone jack and an adapter cable (not included). Summing The LC8i sums its input signals together, even if they've been crossed over for tweeters, mids, and subs by the factory system. That way, you can count on a strong, smooth, full-range signal for your processors and amps. The LC8i features eight RCA preamp outputs that'll handle a 4-way system using tweeters, mid-high speakers, mid-low drivers, and subwoofers. Level-matching with an LED indicator AudioControl makes it easy: set your factory stereo to about 3/4 maximum volume, turn the output level control of the LC8i until the "Maximized" light begins to flicker, then adjust the gain controls on your amps and you're done. You've level-matched the output of your receiver to the amplifier's input, so you can count on getting maximum performance and minimum noise from your system. Convenience The included dash-mounted wired remote allows you to adjust the volume of the auxiliary channel and bass while you're on the go. The speaker-level inputs sense incoming signals and turn on the LC8i, while a built-in 12-volt trigger turns on your amps as well. If your factory system only has channels for highs, mids, and lows, for example, AutoMode(tm) will create the output you can use for your subwoofers.
