MEAN WELL LPV-20-24 AC-DC Power Supply Enclosed LED Single Output 24V

Description

• Primary output voltage (vdc): 24
• Output current (a): 0.84
• Maximum output power (w): 20.2
• Family: lpv-20
• Input voltage (vac): 90 to 264

20.2 W single output switching LED power supply 24 Volts 0.84 Amps features: constant voltage mode power supply universal AC input/full range fully encapsulated with IP67 level withstand 300VAC surge input for 5 seconds protections: short circuit/over current/over voltage fully isolated plastic case cooling by free air convection UL1310 Class 2 power unit pass LPS 100 percent full load burn-in Test low cost, high reliability suitable for LED lighting and moving Sign applications 2 years warranty small and compact size detailed specifications: primary output voltage (VDC): 24 output current (a): 0.84 maximum output power (W): 20.2 family: lpv-20 input voltage (VAC): 90 to 264 input frequency: 47 to 63 maximum input current (a): 0.55 output connector Type: stripped and tinned number of outputs: 1 product Type: AC to DC power supply efficiency ( percent ): 83 minimum isolation voltage: 3000V operating temperature-min (CEL): -30 operating temperature-max (CEL): 70 Length (inch): 4.64 width (inch): 1.37 height (inch): 1.02.
