Worldpeak Lightning Protector F Male to N Male 90V Discharge Gas Tube DC-3GHZ Surge Arrester

Description

• Lightning arrestor,with F-male Connectors 75 ohm in two side, Similar to 859992 75 Ohm Lightning Surge Protector,Protects signal boosters from lightning strikes, Requires additional ground cable
• Surge protector coaxial,Body brass nickel plated,Teflon(PTFE) Insulator for a reliable signal every time
• Coax surge protector,Frequency Range up to 3 Ghz / Attenuation less than 0.2 dB / VSWR less than 1.2
• Arrestor has a replaceable gas discharge element with High Surge Power Capability ( 90V Gas tube)
• F Surge protector should be installed as close a possible to the equipment to be protected, often at the point where the coax cable enters the building. They can also be installed near the antenna for additional protection

Size:Lightning arrester F female to female

1.Materials & Plated: Body brass nickel plated
Teflon(PTFE) Insulator for a reliable signal every time
Connectors: F male to F male 75 ohm RoHS compliant

2.Electricail Characteristics
Impedance:75 ohm
Contact Resistance:Center conductor 1.5m, Outer conductor 1m
Max Power:50W
Discharge current capacity(kA@8/20S):10
Insulation Resistance : 5000M
Durability : 500 cycles
Temperature range: -40C to +85 C
Frequency Range up to 3 GHz Attenuation is less than 0.2 dB
VSWR less than 1.2

3.Package include: 1 piece surge protector

4. Protects signal boosters from lightning strikes Prevent a lightning strike from destroying your electrical system. The 75 ohm Lightning Surge Protector with F-male Connectors can be installed to prevent expensive damage from incapacitating your circuitry. The Lightning Surge Protector safeguards your amplifier and boosted devices from power surges caused by lightning strikes to antennas mounted outside This lightning protector is specifically for 75 ohm systems. Lightning surge protector for Coaxial cable. They boast an insertion loss of less than 0.2 dB. Arresters should be installed as close a possible to the equipment to be protected, often at the point where the coax cable enters the building. They can also be installed near the antenna for additional protection.
