WT32-SC01 Plus 16MB esp32 LCD hmi LCD Board esp32 Development Board with 3.5 LCD IPS Display Touch Screen(with Programer)

Description

• Wide Operating Temperature:Designed to function reliably in a broad range from -20C to 70C.
• Extensive Power Management:Includes two LDOS outputs at 3.3V for efficient power distribution.
• Integrated WIFI Module:Equipped with a WT32-S3-WROVER-N16R2 WIFI module for seamless wireless connectivity.
• Wt32 Sc01 Plus|Wt32 Sc01 Plus Lcd|Capacitive Touch Screen:Features a responsive 3.5 inch capacitive touch pad for intuitive user interaction.
• High-Resolution Display:Boasts a 480*320 resolution for clear, crisp visuals on the 3.5 inch LCD touch Screen.

Brief introduction
1.WT32-SC01 Plus is a development board for visual touch screen, the board is equipped with GUI platform firmwaredeveloped independently, support graphic drag and drop programming to help users complete the development of customized control platform.
2. The main controller ofWT32-SC01 Plus development board adopts WT32-S3-WROVER-N16R2 module, this module is a general-purpose WiFi + BT + BLE MCU module, 16MB SPI flash and 2MB PSRAM are configured in.
3. WT32-SC01 Plus development board can also develop and debug functions such as buttons, voice and camera through the expansion interfaces on both sides, greatly shorten the development cycle of users.
Specification details
==========
Hign-concerned Chemical : None
Type : Logic ICs
Origin : Mainland China
Condition : New
Display : 3.5 inch, LCD touch Screen
Resolition : 480*320
Screen Type : Capacitive Touch pad
WIFI Module : WT32-S3-WROVER-N16R2
Capacity : 2Mbyte PSRAM+ 16Mbyte Flash
Power management : Two LDOS of 3.3V output,
Power supply : DC 5V 2A
working current : 240mA
Temperature : -20C~70C
Dimensions : 60mm*92mm*10.8mm
